Socket-weld and threaded flanges
For small-bore lines up to about 2 inch: socket-weld flanges take a fillet weld, threaded flanges need no welding at all.
About socket-weld and threaded flanges
In a socket-weld flange (SW) the pipe sits in a counterbore and is fillet-welded. The socket bore is machined to the pipe schedule, so state it with the order.
Threaded flanges (TH) are tapped NPT to ASME B1.20.1 and are used where welding is not allowed, such as in some hazardous areas.
Where it is used
- Instrument, sample and drain lines
- Chemical injection lines
- Hydraulic and utility small-bore piping
- Areas where hot work is restricted (threaded)
